IP-1000 LED ANALYZER

Dedicated for Testing of LEDs

The IP-1000 is a specialized device used to inspect LED characteristics that are difficult to evaluate using standard camera-based systems. It’s ideal for verifying LED lighting, blinking patterns, rotation, and color accuracy in real-time.

Product Image



  • Available in 24-channel and 48-channel models
  • Expandable up to 384 channels for large-scale LED arrays

Product Specifications

Model Number

IP-1000-24-CH

24 Channel  76mm(D) x 105mm(W) x 31mm(H)

Model Number

IP-1000-48-CH

48 Channel  76mm(D) x 145mm(W) x 31mm(H)

Baud Rate

115200bps

Data

8 Bit

Parity

None

Stop-Bit

1

Flow Control

None

Hue

0~360

Saturation

0~0.999

Luminance

0~0.999

Brightness

0~255

RGB

0~4095

IP-1000 Inspection Focus

Color

Brightness

Brightness

Color differences between LEDs are easily identified.

Brightness

Brightness

Brightness

Software calculate an expected area which signifies the brightness of each LED tested.

Chroma

Brightness

Chroma

Using a translated number values calculated by the software, it is capable of detecting variances of each colors.
